Inverter Welding Machines

Inverter Welding Machines
Inverter Welding Machines
Product Code : TIG
Brand Name : ELECTRONICS DEVICES
Price And Quantity
  • Minimum Order Quantity
  • 01
  • Unit of Measure
  • Unit/Units
Product Description

Inverter Welding Machines

Relying on the technical expertise & profound knowledge of our team, we have been successful in carving a niche for ourselves as a prominent manufacturer, supplier and exporter of Inverter Welding Machines.  With the support of our skilled manpower, we manufacture these welding machines using sophisticated technology. Inverter Welding Machines are appreciated among our clients for their high arc stability, high efficiency and spatter-free welding features. These machines are widely used in various industries for welding different kinds of metals.

Technical Specifications:

Rated Input Voltage

1-phase 230V + 10% 50/60 Hz

Rated Power (KVA) at 100%

5. 1 KVA

Rated Current Duty Cycle

70% @ 170 A
100% @ 130 A

OCV-DC

80 V (nominal)
20 V (energy saving mode)

Energy Save

In built


Protection:


1) Thermal Shutdown

Yes

2) Under Voltage

Yes

3) Over Current

Yes

4) IGBT Peak Current

Yes

Insulation Class

Class F

Cooling

Forced air cooling

Output Current Range

5-170 A

Ignition Type

Lift-Arc (Contact)

Arc Force

Auto adjusted

Hot Start Current

30%

Hot Start Duration (Approx)

300 m Sec.

Arc Breaking Control

In built

Peak Current

170 A


High Frequency


1) Up Slope Time

0.1 - 10.0 Sec

2) Down Slope Time

0.1 - 10.0 Sec


DC Pulse TIG


1) Base Current

-

2) Peak Time

-

3) Base Time

-

Gas Pre-flow

In built

Gas Post-flow

0.1 Sec/20 A

D x W x H (mm)

400mm X 190mm X 280mm

Weight

12 Kgs

F.A.N. (Fan As Needed)

Optional

Digital Ammeter

In built

Process Memory Recall

In built

Gas Solenoid Valve

Optional

Further details:

The manufactured inverter based welding machine which are made with latest inverter technology that also displays . They have robust design body which is easy to maintain and simple to operate. Due to their technological superiority, they are easy to install and produce less noise on operation.
